PRODUCT DETAILS

Series: Symphony
SKU: 78SYMSNO1224
Size: 12" x 24"*
Thickness: 9 mm
Composition: Coloured Body Glazed Porcelain
Finish: Matte
Stocked: QuickSHIP:
1-2 days
?

Stock Status:

This product is stocked in our Central Service Center and will deliver in 24-48 hours
Country: Italy
Sizes listed are approximate. Actual sizes with acceptable variances may be listed in the brochure.

TRIM

View the Brochure for available or recommended trim options.

TECHNICAL INFORMATION

Surface Rating: Slip Resistance: R9
SLIP: DCOF > .42 Wet ?

HOW IS SLIP MEASURED?

Coefficient of friction (COF) is the measurement of a tile's frictional resistance, closely related to traction and slipperiness. Both static and dynamic measurements can be taken. Static coefficient of friction (SCOF) is the frictional resistance one pushes against when starting in motion. Dynamic coefficient of friction (DCOF) is the frictional resistance one pushes against when already in motion. For SCOF and DCOF, a slip occurs when pushing off with more force than the surface can resist. That can happen when the angle of the force changes (e.g., pushing off harder while pressing down less) or when the floor surface becomes more slippery than anticipated.

While many tile products still show a "COF" value, many manufacturers have stopped reporting coefficient of friction per the ASTM C1028 method because the standard for tile floors has changed. There is now a >0.42 requirement, measured per the DCOF AcuTest℠, for level interior tiles that will be walked on when wet.

Slip Resistance may also be measured using a Pendulum Test.
Class 0: Dry indoor areas only.
Class 1: Dry indoor with slope less than 6 degrees.
Class 2: Wet indoor areas (e.g. bathrooms, kitchen, pool surrounds). Dry indoor areas with slopes or stair steps.
Class 3: Indoor areas where, as well as water, other lubricants are present that can reduce slip resistance (e.g. commercial kitchens, garages, industrial floors, etc.). External areas.
Shade Variation: HIGH ?
shade variation rating chart

Shade Variation Rating: HIGH

While the colors present on a single piece of tile will be indicative on the colors to be expected on the other tiles, the amount of colors on each piece may vary significantly.”
Eco-Certification GBC Italia ?
The Green Building Council (GBC), is a non-profit trade organization that promotes sustainability in how buildings are designed, built and operated.

The USGBC is best known for the development of the Leadership in Energy and Environmental Design (LEED) rating system and Greenbuild, a green building conference that promotes the green building industry, including environmentally responsible materials, sustainable architecture techniques and public policy.
FAQs: Click here for Information about Tile

RELATED ITEMS

Items in GREEN are available via QuickSHIP

12" x 12"
(Matte)

12" x 24"
(Matte)
Items in GREEN are available via QuickSHIP

12" x 12"
(Matte)

12" x 24"
(Matte)

OTHER COLORS


78SYMMOO1224
(Matte)

78SYMPER1224
(Matte)

78SYMSNO1224
(Matte)

78SYMMOO1224
(Matte)

78SYMPER1224
(Matte)

78SYMSNO1224
(Matte)

CATALOGS


Symphony Brochure

Technical Specs


Care + Maintenance
TRIM

View the Brochure for available or recommended trim options.
TECHNICAL INFORMATION
Surface Rating: Slip Resistance: R9
SLIP: DCOF > .42 Wet ?

HOW IS SLIP MEASURED?

Coefficient of friction (COF) is the measurement of a tile's frictional resistance, closely related to traction and slipperiness. Both static and dynamic measurements can be taken. Static coefficient of friction (SCOF) is the frictional resistance one pushes against when starting in motion. Dynamic coefficient of friction (DCOF) is the frictional resistance one pushes against when already in motion. For SCOF and DCOF, a slip occurs when pushing off with more force than the surface can resist. That can happen when the angle of the force changes (e.g., pushing off harder while pressing down less) or when the floor surface becomes more slippery than anticipated.

Slip Resistance may be measured using a Pendulum Test.
Class 0: Dry indoor areas only.
Class 1: Dry indoor with slope less than 6 degrees.
Class 2: Wet indoor areas (e.g. bathrooms, kitchen, pool surrounds). Dry indoor areas with slopes or stair steps.
Class 3: Indoor areas where, as well as water, other lubricants are present that can reduce slip resistance (e.g. commercial kitchens, garages, industrial floors, etc.). External areas.

Slip Resistance may also be measured using a Ramp Test.
Shod Ramp Test: R9 (minimal) to R13 (maximum)
Barefoot Ramp Test: A (minimal) to B (maximum)
Shade Variation: HIGH ?
shade variation rating chart

Shade Variation Rating: HIGH

While the colors present on a single piece of tile will be indicative on the colors to be expected on the other tiles, the amount of colors on each piece may vary significantly.”
Eco-Certification GBC Italia ?

Environmental Rating: GBC Italia

The Green Building Council (GBC), is a non-profit trade organization that promotes sustainability in how buildings are designed, built and operated.

The USGBC is best known for the development of the Leadership in Energy and Environmental Design (LEED) rating system and Greenbuild, a green building conference that promotes the green building industry, including environmentally responsible materials, sustainable architecture techniques and public policy.
FAQs: Click here for Information about Tile
